Product Description

Intimidator Hybrid 140SR

EVE P-130 RGB is a robust RGB wash light designed for mobile lighting entertainers. Interchangeable magnetic lenses are included to alter the beam to desired angles. EVE P-130 RGB has a sturdy cast aluminum housing that provides extra strength without added weight. D-Fi USB compatibility is also onboard providing the option for wireless master/slave or DMX control. Its fanless design ensures 100% silent operation and the unit’s high-frequency LED dimming offers flicker-free operation perfect for video use. EVE P-130 RGB has a built-in gel frame holder and 6¼-inch accessory slot to hold barn doors. Flexible control connection options are onboard with both 3- and 5-pin DMX connectors. PowerCON®-compatible power input/output connections allow secure power linking.

Specifications

DMX Channels: 13 or 19
DMX Connectors: 3-pin XLR
Pan and Tilt: 540°/270°
Pan and Tilt Ranges: 180°, 360°, 540° pan/90°, 180°, 270° tilt
Colors: 12 + white, split colors, continuous scroll at variable speeds
Gobos: wheel (1): 9 + open, rotating, indexing, interchangeable, slot-n-lock, continuous scroll at variable speeds
wheel (2): 17 + open, aluminum, continuous scroll at variable speeds
Light Source: (included): Osram Sirius HRI 140 W discharge lamp (6,000 hrs)
(optional): Osram Sirius HRI 132 W discharge lamp (6,000 hrs)
Strobe Rate: 0 to 20 Hz
Zoom Angle: (beam): 3° to 11°
(spot): 7° to 21°
(wash): 14° to 28°
Illuminance: (3° beam): 382,000 lux @ 5 m
(7° spot): 104,700 lux @ 5 m
(14° wash): 4,680 lux @ 5 m
Power Linking: 3 units @ 120 V; 6 units @ 230 V
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current: 260 W, 2.5 A @ 120 V, 60 Hz
254 W, 1.3 A @ 230 V, 50 Hz
Gobo Size: (rotating): 13.7 mm outside, 11 mm image, 1 mm max thickness
Weight: 33.4 lb (15.2 kg)
Size: 12.6 x 8.6 x 20.2 in (322 x 220 x 513 mm)
Approvals: CE, MET
Gobo wheel: (1): 9 + open, rotating, interchangeable, slot-n-lock, continuous scroll at variable speeds
(2): 17 + open, metal, continuous scroll at variable speeds
Optional Controllers: IRC - 6
Prism: (1): 8-facet round, bidirectional rotation at variable speeds
Prism: (2): 6-facet linear, bidirectional rotation at variable speeds
