Product Description

COREpar UV USB

A Compact UV wash with COB (Chip-on-Board) LED technology, COREpar UV USB offers D-Fi USB compatibility for wireless master/slave or DMX control. The COREpar UV USB includes a separate magnetic lens to provide the ﬂexibility to go from an ultra-wide wash to a narrow beam in seconds. High frequency LED dimming achieves smooth LED fades and ensures a ﬂicker-free performance in video applications. Multiple control options include DMX, master/slave and sound activation modes as well as wireless control thanks to D-Fi USB compatibility.

Specifications

DMX Channels: 1 or 5
DMX Connectors: 3-pin XLR
Light Source: 1 COB LED (UV) 70 W, (1.5 A), 50,000 hours life expectancy
Strobe Rate: 0 to 33 Hz
PWM Frequency: 2,000 Hz
Coverage Angle: 100° without Fresnel lens, 50° with Fresnel lens
Power Linking: 8 units @ 120 V; 15 units @ 230 V
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current: 67 W, 0.975 A @ 120 V, 60 Hz
65 W, 0.517 A @ 230 V, 50 Hz
Weight: 4.6 lb (2.1 kg)
Size: 5.5 x 7.9 x 10 in (139 x 200 x 253 mm)
Approvals: CE
Optional Controllers: IRC-6, D-Fi USB
Wavelength: 390 to 400 nm
