Product Description
COREpar 40 USB
Our COREpar 40 USB produces a full spectrum of light with the unsurpassed color mixing of COB (Chip-on-Board) technology and includes a separate magnetic lens to provide the flexibility to go from an ultra-wide wash to a narrow beam in seconds. High frequency LED dimming achieves smooth LED fades and ensures a flicker-free performance in video applications. Multiple control options include DMX, master/slave and sound activation modes as well as wireless control thanks to D-Fi USB compatibility. Point-and-shoot operation of static colors and automated programs is also possible with the optional IRC-6 remote control (sold separately).. Great FIXTURE!
Specifications
- DMX Channels: 3 or 8
- DMX Connectors: 3-pin XLR
- Light Source: 1 COB LED (tri-color RGB) 40 W (2 A), 50,000 hours life expectancy
- Strobe Rate: 0 to 33 Hz
- PWM Frequency: 2,000 Hz
- Beam Angle: 40° (without lens)
20° (with lens) - Field Angle: 85° (without lens)
28° (with lens) - Illuminance: 243 lux @ 2 m (without lens)
1,660 lux @ 2 m (with lens) - Power Linking: 11 units @ 120 V; 21 units @ 230 V
- Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
- Power and Current: 47 W, 0.7 A @ 120 V, 60 Hz
46W, 0.4 A @ 230 V, 50 Hz - Weight: 3.4 lb (1.6 kg)
- Size: 5.2 x 7.4 x 9.5 in (132 x 189 x 242 mm)
- Approvals: CE
- Optional Controllers: IRC-6
What's Included
- COREpar 40 USB
- Power cord
- Magnetic Fresnel lens
- Warranty card
- Quick Reference Guide
- Hanging bracket with mounting
